AT6108Z High-Efficiency DCM/CCM Multi-Mode Operation Power Factor Correction Controller
AT6108Z High-Efficiency DCM/CCM Multi-Mode Operation Power Factor Correction Controller
General Description
AT6108Z is an active power factor corrected controller to drive PFC boost stages base on ATK
patented Pseudo Digital Control (PDC) method.
In PDC loop, AT6108Z could operates in traditional fixed frequency operation for Continuous Conduction
Mode (CCM) in heavy loading and Discontinuous Conduction Mode (DCM) in lighter loading.
The loop stability and response of operations is well controlled by PDC Loop. AT6108Z features a robust
suite of protection features to properly handle an array of power supply operating and fault condition.
The devices is available in PSOP-8L package and requires few external devices for operation.
AT6108Z is an active power factor corrected controller to drive PFC boost stages base on ATK
patented Pseudo Digital Control (PDC) method.
In PDC loop, AT6108Z could operates in traditional fixed frequency operation for Continuous Conduction
Mode (CCM) in heavy loading and Discontinuous Conduction Mode (DCM) in lighter loading.
The loop stability and response of operations is well controlled by PDC Loop. AT6108Z features a robust
suite of protection features to properly handle an array of power supply operating and fault condition.
The devices is available in PSOP-8L package and requires few external devices for operation.
詳細介紹
◻ Pseudo Digital Control Loop without Analog Multiplier (patent protected)
◻ Quick Transient Response
◻ Intelligent AC Power Sag Protection
◻ DCM/CCM operation
◻ Programmable CCM Operation Frequency 18kHz~130kHz
◻ Sourcing 1A/Sinking 1A High Drive Capability Driver
◻ Brown In/Out protection
◻ Reduced Current Sense Resistor Value
◻ 24.5kHz Operation Frequency in Light Load
◻ Burst Operation in Ultra-Light Load
◻ Bias-Supply UVLO, Over-Voltage Protection,Open-Loop Detection
◻ PSOP-8L Package
Applications
◻ High Efficiency Server and Desktop Power Supplies
◻ Telecom Rectifiers
◻ High Power Adaptor
◻ Off-Line Appliances Requiring Power Factor Correction
◻ High Power SMPS
◻ Single stage PFC low ATHD for LED Driver
